desktop high speed rotary laser engraving machine

Payment Type:	L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm:	FOB,CFR,CIF,EXW,FCA,CPT,CIP
Min. Order:	1 Set/Sets
Delivery Time:	20 Days

Contact Now

Basic Info

Model No.: YH-1290

Application: Leather Industry, Domestic, Carpentry, Printing & Packaging, Construction Industry, Molds & Dies, Crafts Industr, Advertising Industry, Other

Cooling System: Water Cooling

Applicable Material: Other

Engraving Area: 600*900mm

Laser Power: 80w/100w/130w

Laser Type: CO2 LASER TUBE

Engraving Speed: 0~1000mm/s

Resetting Positioning Accuracy: 0.015mm

Power Supply: 220V±10% 50HZ Or 110V±10% 60HZ

Cutting Depth: Acrylic 0-30mm(other Depths Depend On Other Materials)

Minimum Shaping Character: 1.5*1.5mm

Software Supported: PLT/DXF/BMP/JPG/GIF/PGN/TIF Etc.

Laser Tube (Life Hours): 10000hours

Additional Info

Packaging: plywood case

Brand: YIHAI

Transportation: Ocean,Land,Air

Place of Origin: CHINA

Supply Ability: 200

Port: QINGDAO,TIANJIN,SHANGHAI

Product Description

Professional manufacturer!!! mobile laser engraving machine

1. CO2 Glass sealed laser tube

(China famous RECI brand,Good beam mode stability,service time over 6000~10000 hours )

2.Laser Power

good quality and stable power output to extend the laser tube service time.

3.Imported focus lens( High transmittance,good focusing effect and stability

4.DSP control system

USB interface,support online/offline work,English language system,Adjustable cutting speed and power

5. 3 Phase Stepper motor drive and belt transmission, better precision

6.Linear guide rails:Taiwan made famous

7.Industrial Cooling System
The constant water temperature,ensure laser tube a longer service time and high stability

8.Exhaust Fan: exhaust dust and smoke device

9.Electical Magic Air compressor: the huff protection,protect the laser head focus lens clean

10.Emergency Stop

11.Honeycomb or Knives or Lifting platform worktable optional
Honeycomb worktable for cutting fabric leather etc soft material
Aluminum knife worktable for cutting acrylic etc hard material

Lifting platform worktable for rotary device.

12.Routeway feeding:allow users of roll material with unlimited length

13.Optional up & down adjustable worktable:Can engrave & cut different height materials

14.The alarm device optional

15.Portable laser cutting machine: with wheels , easy to move and fixed

Muti-Function:Cut & Engrave

CO2 laser cutting machine use to fine cut /engrave/hollow out on many different type of nonmetallic materials with intricate shapes,graphics,text and logos

CO2 laser cutting engraving machine can work in follow materials

Material	Cut	Engraveoo
Acrylic \| Plexiglass \| Pmma\| Perspex	♦	♦
Organic board \| Double color plate	♦	♦
Wood \| Bamboo \| Veneer \| MDF	♦	♦
Leather \|Pig leather \|Cow Leather \|sheep leather	♦	♦
Fabric \|Cloth \| Textile	♦	♦
Wool Felt	♦	♦
Paper \| Cardboard \| Chipboard\|Press Board	♦	♦
Ceramic \| Tile\| Marble		♦
Plastic	♦	♦
Fiber glass		♦

Technical Parameter

Type	YH-6090
Engraving Area	600×900mm
Laser Power	80W/100W/130W
Laser Type	CO2 Laser Tube
Engraving Speed	0~1000mm/s
Cutting Speed	0~600mm/s
Resetting Positioning Accuracy	0.015mm
Cutting Depth	Acrylic 0-30mm(other depths depend on other materials)
Minimum Shaping Character	1.5×1.5mm
Power Supply	220V±10% 50HZ or 110V±10% 60HZ
Gross Power	1600W
Software Supported	Art cut , CorelDraw, Photoshop, AutoCAD
Graphic Format Supported	PLT/DXF/BMP/JPG/GIF/PGN/TIF etc.
Maximum Height of Materials to Engrave	300 mm
Laser Tube (Life Hours)	10000hours
Equipment Dimensions(mm)	1800X1400X1300 MM
Assistant Equipment	Water Cooling System, Exhaust Fan
Recommended Spare Parts/ Consumables	Laser Tube and Lens

FAQS:

1.what software do we use? Is it difficult?

We use lasercut5.3 software, it`s very easy to learn,. we will provide you the photo and Video.

All machines are CE approved. Machine has 1 year wararnty.

2.how long does it take for production?

3-7working days after receive your deposit.

3.Which kind of machine is more suit for me?

It is according the material and processing thickness and the working area .

4.How to support me if i don't know how to use it?

free training within the warranty by phone and mail or skype.

5.How transport?

By sea

6. If machine have any problem after I ordered it, how could I do?

Free parts send to you in machine warranty period if machine have any problem.
